제품 세부 정보
원래 장소: 중국
브랜드 이름: HONGBAO
인증: PED, ISO9001,DNV
모델 번호: HG-OP
지불 및 배송 조건
최소 주문 수량: 1mt
가격: negotiable
포장 세부 사항: 필요에 따라
배달 시간: 협상 가능
지불 조건: 신용장, 전신환
공급 능력: 3000mt/월
강철 등급: |
30CrMo |
실행 표준: |
ASTM A519, DIN2391, EN10305-1 |
OD 범위: |
30-139.7mm |
WT 범위: |
3-19mm |
강철 등급: |
30CrMo |
실행 표준: |
ASTM A519, DIN2391, EN10305-1 |
OD 범위: |
30-139.7mm |
WT 범위: |
3-19mm |
Chemical Composition
| Steel Grade | C | Si | Mn | P | S | Cr | Mo | B |
|
4130
|
0.28-0.33 | 0.15-0.35 | 0.40-0.60 | ≤0.040 | ≤0.040 | 0.80-1.10 | 0.15-0.25 | |
| 4140 | 0.38-0.43 | 0.15-0.35 | 0.75-1.00 | ≤0.040 | ≤0.040 | 0.80-1.10 | 0.15-0.25 | |
| 45MnMoB | 0.43-0.48 | 0.17-0.37 | 1.05-1.35 | ≤0.020 | ≤0.015 | 0.20-0.25 | 0.001-0.005 | |
|
1541
|
0.36-0.44 | - | 1.35-1.65 | ≤0.040 | ≤0.050 | |||
|
30CrMnSiA
|
0.28-0.34 | 0.90-1.20 | 0.80-1.10 | ≤0.020 | ≤0.015 | 0.80-1.10 |
Mechanical Properties
|
Steel Grade
|
Deliver Condition | Tensile Strength(Mpa) | Yield Strength(Mpa) | Elongation(%) | Hardness(HRC) |
| 4130 | + SR | ≥813 | ≥690 | ≥15% | ≥24 |
| 4140 | QT | ≥950 | ≥850 | ≥14% | 28 - 33 |
| 45MnMoB | + N | ≥790 | ≥600 | ≥14% | - |
| 1541 | + SR | ≥813 | ≥690 | ≥15% | ≥24 |
| 30CrMnSiA | QT | ≥850 | ≥750 | ≥14% | 26 - 31 |
Delivery Condition:
1. Stress Relief Annealing after Cold Working (+SR) (BKS)
2. Normalizing (+N) (NBK)
3. Quenching & Tempering (QT)
FAQ:
1. Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality.
You need to in charge of Express costs.
2. How about your production capacity?
3000 tons/Month.
3. What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.
4. Where is your factory?
Zhangjiagang city, 1.5 hours away from Shanghai.
5. How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
1). Tube Standard
2). Steel Grade
3). Tube Size and Size Tolerance
4). Tube length
5). Quantity
6). If any special requirements
6. How about the minimum order quantity?
Normally for one size above 1 ton.
Welcome to contact us! Thanks.
